Fortress Structural Cantilever Slide Gate

Product Notes

• Closes single clear opening widths up to 40’ and double clear openings up to 80’.
• For larger clear opening widths contact TYMETAL. Clear opening widths for all security gates will vary depending on several factors, including infill options, wind load, and location. Custom options are available.

Product Summary

The Fortress Structural Cantilever Slide Gate is a cantilever system best suited for larger openings than can be handled by a typical heavy-duty gate due to its double-track design. These strong yet versatile sliding security gates are appropriate for openings up to 40 feet for singles and up to 80 feet for doubles. Contact us today to discuss this barrier in more detail. We also invite you to request drawings and specifications and take advantage of our extensive in-house resources.

Features & Benefits

• Fabricated from aluminum alloy extrusions for light weight and durability; the standard design closes single clear openings up to 40 feet wide.
• Multi-panel sliding gate designs available for heights above 8 feet.
• Top primary member is a custom 3 inch x 5 inch structural aluminum extrusion.  The bottom member is either 2 inch x 5 inch aluminum structural tube or 5 inch structural channel for larger openings.
• Vertical members at the ends of the frame have a cross section of no less than 2 inches x 2 inches.
• Separate semi-enclosed double tracks of extruded aluminum alloy welded to the top primary member.
• Gate is supported by four posts and two tracks containing self-aligning, 4-wheeled, sealed lubricant ball-bearing truck assemblies.
• Self-lubricating polymer guide wheels are provided for the bottoms of the support posts.
• Cross-bracing of 1/4 inch diameter galvanized steel cable for vertical adjustment.

Quality Commercial Sliding Gates

Do you have a large opening in your business’s location that needs to be protected? Look no further than TYMETAL for your security gate needs. We offer a high-quality Fortress Structural Cantilever Slide Gate that will protect your business and exceed your expectations. Our top-notch gate is designed for year-round use and uses stainless steel cables, double tracks, and more. Contact us today to learn more.
